Aruba AP-504 (Internal Antenna) Access Points
High performance Wi-Fi 6 access points for medium-density deployments



Aruba AP-504 (Internal Antenna) Access Point

Aruba Networks Products
Aruba Wireless Access Points
Aruba AP-504 (Internal Antenna) (RW) AP
Aruba AP-504 (Internal Antenna) with 802.11ax (Wi-Fi 6)
#R2H23A
Our Price: Request a Quote
Get a Quote
(Qty 5) Aruba AP-504 802.11ax 1.77 Gbit/s Wireless Access Point
#R2H23A-Promo
Our Price: Request a Quote
Get a Quote
Aruba AP-504 (Internal Antenna) TAA (RW) AP
#R2H34A
Our Price: Request a Quote
Get a Quote

Click here to jump to more pricing!

Please Note: All prices displayed are Ex-VAT. 20% VAT is added during the checkout process.

Overview:

The Aruba 500 series access points, with Wi-Fi 6 (802.11ax) technology and Aruba’s intelligent software innovations, deliver high performance connectivity for mobile and IoT devices in any environment.

The 500 series is designed to simultaneously serve multiple clients and traffic types in dense environments, and boosts overall network performance by up to 400% compared to 802.11ac APs.

The 500 Series also provides differentiated capabilities that include AI-powered RF optimization, Live upgrades, WPA3 and Enhanced Open certified security, and unified wired and wireless policy with Dynamic Segmentation.

Additionally, Green AP energy savings are available when Aruba’s AI/ML capabilities are enabled.

Available Models for 500 Series

Aruba AP-505 (Internal Antenna)

Aruba AP-504 (External Antenna)

Why Aruba 504 Series?

firewall

Incredible Efficiency

Aruba's ClientMatch, part of Aruba's AI-powered mobility solution, groups Wi-Fi 6 and MU-MIMO capable clients.

performance

Unsurpassed client experiences

Aruba's unique Smart PoE allows for the use of existing switching infrastructure to power up APs

iot ready

IoT and location ready

Leverage your Wi-Fi infrastructure to support Zigbee and Bluetooth devices and applications

Related Products

Aruba Central

Cloud-native network operations that provides unified management, AI and security for WLAN, LAN and SD-WAN.

Learn More

Aruba ClearPass

Dynamic role-based access control and policy management for wired and wireless networks

Learn More

Specifications:

WI-FI RADIO SPECIFICATIONS
Models:
AP-504
AP-505
AP type:
Indoor, dual radio, 5GHz and 2.4GHz 802.11ax 2x2 MIMO
5GHz radio:
Two spatial stream Single User (SU) MIMO for up to 1.2Gbps wireless data rate with individual 2SS HE80 802.11ax client devices, or with two 1SS HE80 802.11ax MU-MIMO capable client devices simultaneously
2.4GHz radio:
Two spatial stream Single User (SU) MIMO for up to 574Mbps wireless data rate with individual 2SS HE40 802.11ax client devices or with two 1SS HE40 802.11ax MU-MIMO capable client devices simultaneously
Maximum number of associated client devices:
Up to 256 associated client devices per radio
Maximum number of BSSIDs:
16 BSSIDs per radio
Supported frequency bands (country-specific restrictions apply):
  • 2.400 to 2.4835GHz
  • 5.150 to 5.250GHz
  • 5.250 to 5.350GHz
  • 5.470 to 5.725GHz
  • 5.725 to 5.850GHz
Available channels:
Dependent on configured regulatory domain
Supported radio technologies:
  • 802.11b: Direct-sequence spread-spectrum (DSSS)
  • 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
  • 802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 8 resource units
Supported modulation types:
  • 802.11b: BPSK, QPSK, CCK
  • 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM (proprietary extension)
  • 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM (proprietary extension)
  • 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11n high-throughput (HT) support:
HT20/40
802.11ac very high throughput (VHT) support:
VHT20/40/80
802.11ax high efficiency (HE) support:
HE20/40/80
Supported data rates (Mbps):
  • 802.11b: 1, 2, 5.5, 11
  • 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
  • 802.11n: 6.5 to 300 (MCS0 to MCS15, HT20 to HT40), 400 with 256-QAM
  • 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2, VHT20 to VHT80), 1,083 with 1024-QAM
  • 802.11ax (2.4GHz): 3.6 to 574 (MCS0 to MCS11, NSS = 1 to 2, HE20 to HE40)
  • 802.11ax (5GHz): 3.6 to 1,201 (MCS0 to MCS11, NSS = 1 to 2, HE20 to HE80)
802.11n/ac packet aggregation:
A-MPDU, A-MSDU
Transmit power:
Configurable in increments of 0.5 dBm
Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements):
2.4 GHz band: +21 dBm (18dBm per chain)
5 GHz band: +21 dBm (18 dBm per chain)
Note: conducted transmit power levels exclude antenna gain. For total (EIRP) transmit power, add antenna gain.
WI-FI ANTENNAS
AP-504
Two (female) RP-SMA connectors for external dual band antennas (A0 and A1, corresponding with radio chains 0 and 1). Worst-case internal loss between radio interface and external antenna connectors (due to diplexing circuitry): 0.7dB in 2.4GHz and 1.3dB in 5GHz.
AP-505
Two integrated dual-band downtilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.9dBi in 2.4GHz and 5.7dBi in 5GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the combined, average pattern is 4.3dBi in 2.4GHz and 5.6dBi in 5GHz.
OTHER INTERFACES
E0: Ethernet wired network port (RJ-45):
  • Auto-sensing link speed (10/100/1000BASE-T) and MDI/MDX
  • PoE-PD: 48Vdc (nominal) 802.3af/at PoE (class 3 or 4)
  • 802.3az Energy Efficient Ethernet (EEE)
DC power interface:
12Vdc (nominal, +/- 5%), accepts 2.1mm/5.5mm center-positive circular plug with 9.5mm length
USB 2.0 host interface (Type A connector):
Capable of sourcing up to 1A / 5W to an attached device
Bluetooth Low Energy (BLE5.0) and Zigbee (802.15.4) radio:
  • BLE: up to 7dBm transmit power (class 1) and -93dBm receive sensitivity (1Mbps)
  • Zigbee: up to 6dBm transmit power and -96dBm receive sensitivity Integrated vertically polarized omnidirectional antenna with roughly 30 degrees downtilt and peak gain of 3.3dBi
Visual indicators (two multi-color LEDs):
For System and Radio status
Reset button:
Factory reset, LED mode control (normal/off)
Serial console interface:
Proprietary, micro-B USB physical jack
Security slot:
Kensington security slot
POWER SOURCES AND POWER CONSUMPTION
The AP supports direct DC power and Power over Ethernet
  • The AP supports direct DC power and Power over Ethernet
  • When both DC and PoE power sources are available, DC power takes priority over PoE units
  • Power sources are sold separately; see the 500 Series Ordering Guide for details
  • When powered by DC or 802.3at (class 4) PoE, the AP will operate without restrictions units
  • When powered by 802.3af (class 3) PoE and with the IPM feature disabled, the AP will disable the USB port. In the same configuration but with IPM enabled, the AP will start up in unrestricted mode, but may dynamically apply restrictions depending on the PoE budget and actual power. The feature restrictions and order can be programmed.
Maximum (worst-case) power consumption (without / with a USB device attached):
  • DC powered: 8.9W / 14.2W
  • PoE powered (802.3at): 11.0W / 16.5W
  • PoE powered (802.3af): 11.0W / 13.5W
  • This assumes that up to 5W is supplied to the attached USB device
Maximum (worst-case) power consumption in idle mode:
4.3W (DC) or 6.1W (PoE)
Maximum (worst-case) power consumption in deep-sleep mode:
1.7W (DC) or 3.3W (PoE)
MECHANICAL SPECIFICATIONS
Dimensions/weight (AP-505; unit, excluding mount bracket):
160mm (W) x 161mm (D) x 37mm (H)
Weight: 500g
Dimensions/weight (AP-505; shipping):
193mm (W) x 183mm (D) x 63mm (H)
Weight: 645g
Mounting details (AP-505):
A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately); see the 500 Series Ordering Guide for details.
MOUNTING DETAILS
  • A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the Aruba mount kits (sold separately); see the ordering Information section below for details.
ENVIRONMENTAL SPECIFICATIONS
Operating conditions
  • Temperature: 0°C to +50°C / +32°F to +122°F
  • Humidity: 5% to 93% non-condensing
  • AP is plenum rated for use in air-handling spaces
  • ETS 300 019 class 3.2 environments
Storage and transportation conditions
  • Temperature: -40°C to +70°C / -40°F to +158°F
  • Humidity: 5% to 93% non-condensing
  • ETS 300 019 classes 1.2 and 2.3 environments
RELIABILITY
Mean Time Between Failure (MTBF):
1.3Mhrs (148yrs) at +25°C operating temperature
REGULATORY AND SAFETY COMPLIANCE
  • AP-504: APIN0504
  • AP-505: APIN0505
Minimum ArubaOS Release:
ArubaOS and Aruba InstantOS 8.6.0.0
Regulatory compliance (for more country-specific regulatory information and approvals, please see your Aruba representative):
  • FCC/ISED
  • CE Marked
  • RED Directive 2014/53/EU
  • EMC Directive 2014/30/EU
  • Low Voltage Directive 2014/35/EU
  • UL/IEC/EN 60950
  • EN 60601-1-1, EN60601-1-2
Certifications:
  • UL2043 plenum rating
  • Wi-Fi Alliance:
    • Wi-Fi CERTIFIED a, b, g, n, ac
    • Wi-Fi CERTIFIED 6 (ax)
    • WPA, WPA2 and WPA3 - Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
    • WMM, WMM-PS, Wi-Fi Vantage, W-Fi Agile Multiband
    • Wi-Fi Location
    • Passpoint (release 2)
  • Bluetooth SIG
  • Ethernet Alliance (PoE, PD device, class 4)

Documentation:

Aruba AP-504 Series Access Points Datasheet (.PDF)

It appears you don't have a PDF plugin for this browser. No biggie... you can click here to download the PDF file.
